Panasonic SC-DP1 User Manual

35
RQT6815
Reference
Specifications
AMPLIFIER SECTION
RMS Output Power both channel driven
10
% total harmonic distortion
1 kHz (Low-channel) 25 W per channel (6 ≠)
8 kHz (High-channel) 25 W per channel (6 ≠)
Total Bi-Amp power 50 W per channel
Total RMS Stereo mode power 100 W
Total RMS Dolby Digital mode power 100 W
FTC Output Power both channel driven
10
% total harmonic distortion
60 Hz–3 kHz (Low-channel) 20 W per channel (6 ≠)
3 kHz–16 kHz (High-channel) 20 W per channel (6 ≠)
Total Bi-Amp power 40 W per channel
Total FTC Power in Stereo mode
(Band 10
% THD) 80 W
Total FTC Power in Dolby Digital mode
(Band 10
% THD) 80 W
Input sensitivity/Input impedance
AUX 250 mV, 19 k≠
FM TUNER SECTION
Frequency range 87.9–107.9 MHz (200-kHz step)
87.5–108.0 MHz (100-kHz step)
Sensitivity 2.5 µV(IHF)
S/N 26 dB 2.2 µV
Antenna terminals 75 ≠ (unbalanced)
Preset station 15
AM TUNER SECTION
Frequency range 520–1710 kHz (10-kHz step)
Sensitivity
S/N 20 dB at 1000 kHz 560 µV/m
Preset station 15
DISC SECTION
Discs played [8 cm (3 z) or 12 cm (5 z)]:
(1) DVD-RAM (DVD-VR compatible)
(2) DVD-Audio
(3) DVD-Video
(4) DVD-R (DVD-Video compatible)
(5) CD-Audio (CD-DA)
(6) Video CD
(7) SVCD (Conforming to IEC62107)
(8) CD-R/CD-RW (CD-DA, Video-CD formatted discs)
(9) MP3/WMA
≥Maximum number of tracks and groups recognizable:
999 tracks and 99 groups
≥Compatible compression rate:
MP3: between 32 kbps and 320 kbps
WMA: between 48 kbps and 192 kbps
(10) JPEG
≥Exif Ver 2.1 JPEG Baseline files
≥Maximum number of pictures and groups recognizable:
3000 pictures and 300 groups
≥Picture resolution: between 320t240 and 6144t4096 pixels
(sub sampling is 4:2:2 or 4:2:0)
(11) HighMAT Level 2 (Audio and Image)
Video
S ignal system NTSC
Output level
Composite video 1 Vp-p (75 ≠)
S-video
Y output level 1 Vp-p (75 ≠)
C output level 0.286 Vp-p (75 ≠)
Component video (Y:green, P
B:blue, PR:red)
Y output level 1 Vp-p (75 ≠)
P
B output level 0.7 Vp-p (75 ≠)
P
R output level 0.7 Vp-p (75 ≠)
Audio
Sampling frequency
CD 44.1 kHz
MP3 32 kHz, 44.1 kHz, 48 kHz
DVD (Linear Audio) 48 kHz, 96 kHz
DVD-Audio 192 kHz
Decoding 16/20/24 bit linear
Number of channels Stereo
Frequency response 20 Hz–20 kHz (i1, j2dB)
Digital audio output
Optical digital output Optical terminal
Pick up
Beam Source Semiconductor Laser
Wavelength
CD/VCD 780 nm
DVD 658 nm
Wow and flutter Less than possible measurement data
D/A converter Delta sigma DAC
SPEAKER SECTION
Type 2 way, 2 speaker system
Speaker units
Tweeter 6 cm (2
3
/8q) cone type 6 ≠
Woofer 10 cm (4q) cone type 6 ≠
Input power High 50 W (Music)
Low 50 W (Music)
Output sound pressure level 81 dB/W (1.0 m)
Crossover frequency 2.2 kHz
Frequency range 47 Hz–32 kHz (j16 dB)
64 Hz–31 kHz (j10 dB)
Dimensions (WtHtD) 158k276k280 mm
(6
7
/32qk10
7
/8qk11
1
/32q)
Mass 2.4 kg (5.3 Ibs)
GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 85 W
Dimensions (WtHtD) 205k123.5k383.5 mm
(8
1
/16qk4
27
/32qk15
3
/32q)
Mass 4.1 kg (9.0 Ibs)
[Note]
1 Specifications are subject to change without notice.
Mass and dimensions are approximate.
2 Total harmonic distortion is measured by the digital spectrum
analyzer.
Power consumption in standby mode 0.9 W

Panasonic SC-DP1 Specifications

Amplifier Specifications

RMS Output Power (Low-channel)	25 W per channel (6 ≠)
RMS Output Power (High-channel)	25 W per channel (6 ≠)
Total Bi-Amp power	50 W per channel
Total RMS Stereo mode power	100 W
Total RMS Dolby Digital mode power	100 W
PMPO Output Power	1000 W
DIN Output Power (Low-channel)	20 W per channel (6 ≠)
DIN Output Power (High-channel)	20 W per channel (6 ≠)
Total DIN Power in Stereo mode	80 W
Total DIN Power in Dolby Digital mode	80 W
AUX Input sensitivity	250 mV
AUX Input impedance	19 k≠

FM Tuner Specifications

Frequency range	87.50–108.00 MHz (50-kHz step)
Sensitivity	2.5 µV (IHF)
S/N 26 dB	2.2 µV
Antenna terminals	75 ≠ (unbalanced)
Preset station	15

AM Tuner Specifications

Frequency range (UK, Europe, Russia)	522–1629 kHz (9-kHz steps)
Frequency range (Australia, N.Z., Southeast Asia)	522–1629 kHz (9-kHz steps)/520–1630 kHz (10-kHz steps)
Sensitivity	560 µV/m
Preset station	15

Speaker Specifications

Type	2 way, 2 speaker system
Tweeter	6 cm cone type 6 ≠
Woofer	10 cm cone type 6 ≠
Input power (High)	50 W (Music)
Input power (Low)	50 W (Music)
Output sound pressure level	81 dB/W (1.0 m)
Crossover frequency	2.2 kHz
Frequency range (16 dB)	47 Hz–32 kHz
Frequency range (10 dB)	64 Hz–31 kHz
Dimensions (WxHxD)	158k276k280 mm
Mass	2.4 kg

General Specifications

Power supply (UK, Australia, N.Z.)	AC 230–240 V, 50 Hz
Power supply (Europe, Russia)	AC 230 V, 50 Hz
Power supply (Southeast Asia except Thailand)	AC 230–240 V, 50/60 Hz
Power supply (Thailand)	AC 220 V, 50 Hz
Power consumption	105 W
Dimensions (WxHxD)	205k123.5k383.5 mm
Mass	4.2 kg
Power consumption in standby mode	1 W
