21
RQT6815
Disc operations
You can use the text information recorded on these discs to find a
track to play.
1 While the menu is displayed
Press [1] while a track is highlighted
to display the contents screen.
2 Press [2, 1] to move through the
tracks and press [ENTER].
To return to the navigation menu
Press [RETURN].
A menu appears after you insert the disc.
Press [3, 4, 2, 1] to select then press
[ENTER].
When you press [ENTER]:
To return to the menu screen
Press [TOP MENU].
To return to the menu above the current one
Press [RETURN].
To change the menu background
Press [GUI DISP].
The background changes to the one recorded on the disc.
Selecting from the lists
1 While playing
Press [MENU].
2 Press [2] then [3, 4] to switch
between the play list, group and
content lists.
3 Press [1] then [3, 4] to select an
item and press [ENTER].
To exit the list screen
Press [MENU].
To use the contents screen to find a track
[CD] (CD text only)
See page 34 for details about WMA/MP3/JPEG and CD text .
SELECT
ENTER RETURN
T 10 /14
MENU
Contents
Track 10 Title/Artist
Pink Island
Long John Platinum
Disc Title/Artist
SHIPWRECKED
ORIGINAL SOUNDTRACK
Playing HighMAT discs
HighMAT and the HighMAT logo are either
trademarks or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
Menu: Takes you to the next menu which shows play lists or
another menu
Play list: play starts
Playlist
Group
Less and less
And when I was born
Quatre gymnopedies
You've made me sad
I can't quit him
Evening glory
Wheeling spin
Velvet Cuppermine
Ziggy Starfish
2
3
4
5
6
7
8
9
10
No Content title
SELECT
ENTER
RETURN
SELECT
NUMBER
09
All By Artist
Content
Group 1
Few times in summer
1
Playing

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic SC-DP1 and is the answer not in the manual?

Panasonic SC-DP1 Specifications

Amplifier Specifications IconAmplifier Specifications
RMS Output Power (Low-channel)25 W per channel (6 ≠)
RMS Output Power (High-channel)25 W per channel (6 ≠)
Total Bi-Amp power50 W per channel
Total RMS Stereo mode power100 W
Total RMS Dolby Digital mode power100 W
PMPO Output Power1000 W
DIN Output Power (Low-channel)20 W per channel (6 ≠)
DIN Output Power (High-channel)20 W per channel (6 ≠)
Total DIN Power in Stereo mode80 W
Total DIN Power in Dolby Digital mode80 W
AUX Input sensitivity250 mV
AUX Input impedance19 k≠
FM Tuner Specifications IconFM Tuner Specifications
Frequency range87.50–108.00 MHz (50-kHz step)
Sensitivity2.5 µV (IHF)
S/N 26 dB2.2 µV
Antenna terminals75 ≠ (unbalanced)
Preset station15
AM Tuner Specifications IconAM Tuner Specifications
Frequency range (UK, Europe, Russia)522–1629 kHz (9-kHz steps)
Frequency range (Australia, N.Z., Southeast Asia)522–1629 kHz (9-kHz steps)/520–1630 kHz (10-kHz steps)
Sensitivity560 µV/m
Preset station15
Speaker Specifications IconSpeaker Specifications
Type2 way, 2 speaker system
Tweeter6 cm cone type 6 ≠
Woofer10 cm cone type 6 ≠
Input power (High)50 W (Music)
Input power (Low)50 W (Music)
Output sound pressure level81 dB/W (1.0 m)
Crossover frequency2.2 kHz
Frequency range (16 dB)47 Hz–32 kHz
Frequency range (10 dB)64 Hz–31 kHz
Dimensions (WxHxD)158k276k280 mm
Mass2.4 kg
General Specifications IconGeneral Specifications
Power supply (UK, Australia, N.Z.)AC 230–240 V, 50 Hz
Power supply (Europe, Russia)AC 230 V, 50 Hz
Power supply (Southeast Asia except Thailand)AC 230–240 V, 50/60 Hz
Power supply (Thailand)AC 220 V, 50 Hz
Power consumption105 W
Dimensions (WxHxD)205k123.5k383.5 mm
Mass4.2 kg
Power consumption in standby mode1 W
