CONNECTION OF OPTIONAL UNITS
I-27
(1) Setting the Exchange line incoming call Answer Time
Sets how long after detection of ringing the unit will answer the call. This setting is set by DIP
switches SW2-2 and SW2-3 of SW2.
Table 6
SW2-2 SW2-3 Exchange line incoming call Response Standby Time Initial setting
OFF OFF 8 Seconds
OFF ON 16 Seconds
ON OFF 32 Seconds
ON ON Immediate answer K
Initial setting
K
(2) Setting the Recording Time
The recording time setting sets the recording time of the response message. This setting is set by
DIP switch SW1-3 of SW1.
Table 7
SW1-3 Recording Time Description
ON Max. 16 seconds When this setting is made, the recording time of the response message becomes
the maximum 16 seconds. Two messages can be recorded.
OFF Max. 32 seconds When this setting is made, the recording time of the response message becomes
the maximum 32 seconds. Only one message can be recorded.
(3) Wait for dialling timer
Sets how long the unit waits for the caller to dial after completion of OGM, before proceeding.
This setting is set by DIP switches SW2-5 and SW2-6 of SW2.
Table 8
SW2-5 SW2-6 Exchange line Response Standby Time Initial setting
OFF OFF 2 Seconds
OFF ON 6 Seconds
ON OFF 10 Seconds K
ON ON 14 Seconds
Table 9
SW2-1 Dial Method Description
OFF Dial “1” not appended When this setting is made, the reception dial from the calling side is dialed as it
is to call up the other party’s extension.
ON Dial “1” appended When this setting is made, the reception dial from the calling side appended
with “1” is dialed to call up the other party’s extension.
This setting must be set when the system is set to voice call up.
Initial setting
K
(4) Setting the Internal Line Call Mode
The internal line call mode setting sets the extension dial mode when a designated extension is
called determining either tone or voice call is used. This setting is set by DIP switch SW2-1 of
SW2.
To Next Page
