Parker AC10 series User Manual

Parameter Reference 15-11
AC10 Inverter
Auxiliary Functions: F600-F650
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F600 DC Braking Function Selection
0: Invalid;
1: braking before starting;
2: braking during stopping;
3: braking during starting and stopping
0 √
F601 Initial Frequency for DC Braking
0.20～50.00
1.00 √
F602 DC Braking efficiency before Starting
0～100
10 √
F603 DC Braking efficiency During Stop 0～100 10 √
F604 Braking Lasting Time Before Starting
0.00～30.00
0.50 √
F605 Braking Lasting Time During Stopping
0.00～30.00
0.50 √
F606 Reserved
F607 Selection of Stalling Adjusting Function
0: invalid;
1: valid
2: Reserved
3: Voltage current control
4: Voltage control
5: Current control
0 √
F608 Stalling Current Adjusting (%)
60～200
160 √
F609
Stalling Voltage Adjusting (％) 110～200
1 phase: 130
3 phase: 140
√
F610 Stalling Protection Judging Time
0.1～3000
60.0 √
F611 Dynamic Braking Threshold (V) 200~1000
Subject to
inverter
model
△
F612 Dynamic Braking Duty Ratio (%)
0～100％
80
╳
F613 Flycatching
0: invalid
1: valid
2: valid at the first time
0
╳
F614 Flycatching Rate Mode
0: Flycatching from frequency
memory
1: Flycatching from max frequency
2: Flycatching from frequency
memory and direction memory
3: Flycatching from max frequency
and direction memory
0
╳
F615 Flycatching Rate
1～100
20
╳
F613 –
F621
Reserved
F622 Dynamic Braking Mode
0: Fixed duty ratio
1: Auto duty ratio
0 √
F627
Current Limiting when Flycatching
50-200
100
╳
F631 VDC Adjustment Selection 0: invalid
Subject to
√
