Parker AC10 series User Manual

12-8 Modbus Communication
AC10 Inverter
12.7 Function Codes Related to Communication
Function Code Function Definition Setting Rang
Mfr’s
Value
F200
Source of start
command
0: Keypad command;
1: Terminal command;
2: Keypad＋Terminal;
3: MODBUS;
4: Keypad＋Terminal＋MODBUS
4
F201
Source of stop
command
0: Keypad command;
1: Terminal command;
2: Keypad＋Terminal;
3: MODBUS;
4: Keypad＋Terminal＋MODBUS
4
F203
Main frequency source
X
0: Digital setting memory;
1: External analog AI1;
2: External analog AI2;
3: Pulse input given;
4: Stage speed control;
0
F900 Inverter Address 1~255 : single inverter address
0: Broadcast address
1
F901 Modbus Mode
Selection
1: ASCII mode
2: RTU mode
1
F903 Parity Check 0: Invalid
1: Odd
2: Even
0
F904 Baud Rate(bps) 0: 1200
1: 2400
2: 4800
3: 9600
4: 19200
3
Set functions code related to communication consonant with the PLC/PC communication
parameters, when inverter communicates with PLC/PC.
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
