Parker AC10 series User Manual

Parameter Reference 15-17
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
2: Analog input AI2
FC07
Torque reference coefficient
0～3.000
3.000
╳
FC08 Reserved
FC09
Torque reference command value (%)
0～300.0
100.0
√
FC10-
FC13
Reserved
FC14 Offset torque reference source
0: Digital given (FC17)
1: Analog input AI1
2: Analog input AI2
0
╳
FC15 Offset torque coefficient 0~0.500 0.500
╳
FC16 Offset torque cut-off frequency (%) 0~100.0 10.00
╳
FC17 Offset torque command value (%) 0~50.0 10.00 √
FC18-
FC21
Reserved
FC22 Forward speed limit source
0: Digital given (FC23)
1: Analog input AI1
2: Analog input AI2
0
╳
FC23 Forward speed limit (%)
0～100.0
10.00
√
FC24 Reverse speed limit source
0: Digital given (FC25)
1: Analog input AI1
2: Analog input AI
0
╳
FC25 Reverse speed limit (%)
0～100.0
10.00
√
FC26-
FC27
Reserved
FC28 Driving torque limit source
0: Digital given (FC30)
1: Analog input AI1
2: Analog input AI2
0
╳
FC29
Driving torque limit coefficient
0～3.000
3.000
╳
FC30
Driving torque limit (%)
0～300.0
200.0
√
FC31
Reserved
FC32
Reserved
FC33
Re
-generating torque limit source
0
: Digital given (FC35)
1
: Analog input AI1
2
: Analog input AI2
0
╳
FC34
Re
-generating torque limit coefficient
0
～3.000
3.000
╳
FC35
Re
-generating torque limit (%)
0
～300.0
200.00
√
FC36
-
FC40
Reserved
Note:
╳ indicating that function code can only be modified in stop state.
√ indicating that function code can be modified both in stop and run state.
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
