Parker AC10 series User Manual

Function Parameters 9-49
AC10 Inverter
FC22 Forward speed limited channel
0: Digital given (FC23)
1: Analog input AI1
2: Analog input AI2
4: Pulse input channel FI
5: Reserved
0
FC23 Forward speed limited (%)
0～100.0
10.0
FC24 Reverse speed limited channel
0: Digital given (FC25)
1: Analog input AI1
2: Analog input AI2
0
FC25 Reverse speed limited (%) 0～100.0 10.00
Speed limited FC23/FC25: if given speed reaches max value, they are used to set percent of
inverter output frequency and max frequency F111.
FC28 Driving torque limit channel
0: Digital given (FC30)
1: Analog input AI1
2: Analog input AI2
4: Pulse input channel FI
5: Reserved
0
FC29 Driving torque limit coefficient
0～3.000
3.000
FC30 Driving torque limit (%)
0～300.0
200.0
FC31 Braking torque limit channel
0: Digital given (FC35)
1: Analog input AI1
2: Analog input AI2
4: Pulse input channel FI
5: Reserved
0
FC34 Braking torque limit coefficient
0～3.000
3.000
FC35 Braking torque limit (%)
0～300.0
200.00
When motor is in the driving status, output torque limit channel is set by FC28, and limit torque
is set by FC29.
When motor is in the re-generating status, re-generating torque limit channel is set by FC31, and limit
torque is set by FC34.
