Parker Compax3 Installation Manual

Parker EME
Specifications
192-121100 N6 June 2008 25
Supported valves and feedback systems
Valves
 D1*FH series
Absolute encoder
 Analog 0..20mA, 4..20mA, ±10V
 Start/Stop - interface
 SSI interface
 EnDat 2.1-interface
 1VSS (max. 400kHz) Interface, 13.5bits /
graduationof the scale
 RS422 encoder (max. 5MHz), internal
quadrature of the resolution
EMC limit values
EMC interference emission
Limit values according to EN 61000-6-4: 2001
for the industrial environment
EMC disturbance immunity
Limit values according to EN 61000-6-2: 2001
for the industrial environment
Environmental requirements Compax3F
General ambient conditions
According to EN 60 721-3-1 to 3-3
Climate (temperature/humidity/barometric
pressure): Class 3K3
Permissible ambient temperature:
Operation
Storage
Transport
0 to +45 C Class 3K3
-25 to +70 C Class 2K3
–25 to +70 C Class 2K3
Tolerated humidity:
No condensation
Operation
Storage
Transport
<= 85% class 3K3
<= 95% class 2K3
<= 95% class 2K3
(Relative humidity)
Elevation of operating site
<=1000m above sea level for 100% load
ratings
<=2000m above sea level for 1% / 100m
power reduction
Please inquire for greater elevations
Mechanic resonances:
EN 60068-2-6 (sinusoidal excitation)
Sealing
IP20 protection class according to EN 60 529
Insulation requirements
Degree of contamination
Level of contamination 2 according to EN 50 178

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
