Parker Compax3 Installation Manual

Specifications
Hydraulics controller
24 192-121100 N6 June 2008
Voltage supply 24VDC
Controller type Compax3 F001 D2
Voltage range
21 - 27VDC
Mains module
with switch-on current limitation, due to
capacitive load
Fuse
MTP miniature circuit breaker or "delayed action
fuse", due to capacitive load
Current drain of the device
0.8A (max. 1.5A)
Total current drain
0.8A + total load of the digital outputs
Ripple
<1Vss
Requirement according to safe extra
low voltage (SELV)
yes
Size / weight
Controller type Compax3 F001 D2
Dimensions: HxWxD [mm]
199x80x130
Weight [kg]
2.0
Housing / protection class
Enclosed metal housing, insulation according to
EN60529 / IP 20
Inputs and outputs
Controller type Compax3 F001 D2
8 control inputs
24VDC / 10kOhm
4 control outputs
active HIGH/short-circuit protected, 24 V / 100
mA
4 analog current inputs
14Bit
2 analog voltage inputs
14Bit
4 analog outputs
16bits, current or voltage
2 analog monitor ouptuts
8bits
COM ports
RS232
 115200 baud
 Word length: 8 bits, 1 start bit, 1 stop bit
 Hardware handshake XON, XOFF
RS485 (2 or 4-wire)
 9600, 19200, 38400, 57600 or 115200
baud
 Word length 7/8 bit, 1 start bit, 1 stop bit
 Parity (can be switched off) even/odd
 2 or 4-wire
4. Specifications

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
