7. Install the Lower casing unit casing cover
Lower casing unit casing cover assembly mounting tool
8. Check whether the shift gear is working properly.
9. Install the water pump assembly.
10. Install the anode and water inlet.
11. Install the propeller and slotted hexagon nut, and place a piece of wood between the
anti-swirl plate and the propeller to prevent the propeller from rotating freely.
Tighten the nut to the specified torque, insert the cotter pin and bend the foot of the
cotter pin. Specified torque: 35 Nm
Note:
If the groove on the nut is not aligned with the cotter pin hole on the propeller shaft, tighten the nut
further until it is aligned.
Install the Lower casing Unit
1. Install the locating pin.
2. Place the shift cam in the forward position. Install the Lower casing unit to the casing
of the Lower casing unit and tighten the bolts to the specified value.
Specified torque: 37 Nm
3. Perform the shift operation and check whether it is operating properly.
4. Inject gear oil into the oil drain screw hole with the pressure filling device.
