66
Apply oil to the bolts before installation.
2. Install oil filter using special tools and tighten it to the specified torque.
Locking torque: 18 Nm
Note:
Before installation, inject oil into the oil channel.
3. Install the exhaust cover, thermostat and thermostat cover.
Tighten them at the specified torque twice in the order indicated on the exhaust cover plate.
Locking torque: First time 6 Nm
First time 12 Nm
6. Install the locating pin, cylinder gasket and cylinder head assembly.
7. Check the keyway position of semicircular key on camshaft
8. Tighten the cylinder head bolts to the specified values in 2 steps according to the
sequence marked on the cylinder head.
Specified torque:
1
st
tightening
M9
23 Nm
2
nd
tightening 46 Nm
1
st
tightening
M6
6 Nm
2
nd
tightening 12 Nm
Attention:
Do not use old cylinder gaskets.
9. Install the timing pulley, driven pulley, timing belt and breather pipe.
Attention:
When installing the timing belt, ensure that the mark on the driven pulley is aligned with the "▼" on
the cylinder head; Ensure that the mark on the timing pulley is aligned with the "▼" on the body.
10. Adjust valve clearance.
11. Install the cylinder head cover and tighten the bolts in the order indicated on the
cylinder head cover.
12. Install electrical system components in reverse order according to the removal sequence
13. Connect the wire of the electrical system.
14. Install the fuel system.
