6 Camera Control for the pco.edge
20 pco.edge User Manual V1.03 © PCO AG, Germany
External Exposure Start
(Auto Sequence respectively)
# of lines
95.3 MHz
(slow scan)
286 MHz
(fast scan)
tjit
1
0 … 27.52 µs
0 … 9.17 µs
tframe
ROI (y)
29.76 ms (max)
10.00 ms (max)
texp
programmable
10 µs … 100 ms
10 µs … 100 ms
tdelay (system)
(tframe – texp)
tif
1
27.52 µs
9.17 µs
External Exposure Control
# of lines
95.3 MHz
(slow scan)
286 MHz
(fast scan)
tjit
1
0 … 27.52 µs
0 … 9.17 µs
tframe
ROI (y)
29.76 ms (max)
10.00 ms (max)
texp
counted
if t
exp
< t
frame
system delay (t
delay
) is
added before exposure
starts
