Appendix
64
pco.edge User Manual V1.03 © PCO AG, Germany
either with USB 3.0 or Camera Link interface, the image data will be
recorded to the computer in real-time.
Memory Structure / Organization
As the memory is software-controlled in both options, it does not matter
how the data are stored. The memory can be organized for ring buffer or
FIFO recording, or for a specified number of images like a “burst” mode.
The pco.edge camera enables all of these possibilities with the integrated
dynamic link libraries and proprietary pco.camware application software.
This allows the customer to select the memory structure and organization
that is optimized for the application at hand.
Recommendations
In the following you can find two exemplary systems for RAID and RAM
storage options that have been successfully tested by PCO for high
performance.
11x Seagate 2TB Constellation ES.2 SATA 6Gb/s
16 GB DDR3 RAM
LSI MegaRAID SAS 9280 16+4 Port 6Gb/s PCI 2.0 x8
Intel® DX79SI motherboard
Intel® Core™ i7-3820 processor 3.6 GHz
500 GB Western Digital RE4 64MB
GeForce GTS 640 2GB (NVIDIA CUDA)
Windows 7 Professional 64 bit
64 GB DDR3 RAM
Intel® DX79SI motherboard
Intel® Core™ i7-3820 processor 3.6 GHz
GeForce GTS 640 2GB (NVIDIA CUDA)
500 GB Western Digital RE4 64MB
Windows 7 Professional 64 bit
Note: items are exemplary and subject to change. Please contact PCO for
current systems.
ASUS mainboards seem to fail generally during the HS-mode test (see
appendix A9) and are not recommended. Other appropriate mainboards,
tested at PCO:
Intel Siler X79
Intel DX58SO2
Gigabyte GA-X58A-UD3R
Supermicro X8DTH-iF (S5520 chipset)
Recommended minimum configuration:
CPU >= 2.4GHz
RAM >= 1066MHz
