- 20 -
3 Precaution for safety
1
5
2
6
3
7
9
4
8
10
PSA011H011A
View X
TSJ011H023
CAUTION FAN
TSJ011H023
CAUTION FAN
TSJ011H022A
TSJ011H022A
TSJ011H022A
TSJ011H078
警 告
WARNING
Never modify or remove the door limit switch.
Otherwise,you may be injured by accidental start of the unit with the door opening.
ドアリミットスイッチの改造、取外しをしないこと。ドア開のままユニットが起動しケガをする恐れ有。
PSA011H011A
PSA011H011A
TMA011H005A
X
tool
4
2
1
4
3
3
2
1
<STEP>
Loosen two bolts.
Apply tool as shown and give tension
to the belt by using the tool as a lever.
Tighten two bolts while applying the tension.
(Tighting torque:24N･m）
Check tension of the belt.
(Nominal tension：300〜350N)
Tu rn off unit operation switch
before starting adjustment
WARNING
《Method of adjusting tension of Alternator Belt》
Front view inside
To Next Page
