Pegasus TFV2000D-E - Daily Inspection; Inspection of the Cooling Water Quantity

- 62 -
7 Inspection
1
5
2
6
3
7
9
4
8
10
Daily inspection
Inspection of the cooling water quantity
CAUTION
Do not perform inspection of the cooling water or rell
it immediately after the sub-engine stopped.
• High temperature steam may blow out and it may cause heat
injury.
Use the designated antifreeze coolant.
• Otherwise, it may cause troubles.
1
Check that the uid level is between "MAX" and "MIN" in the reservoir
tank.
2
When the uid level is lower than "MIN", rell the designated antifreeze
coolant to the level of "MAX".
( Refer to page 70 for the designated antifreeze coolant.)
-MAX-
-MIN-
Reservoir tank
