BRUSH CUTTER EXCELION 2 DH
53_153238-A
Removing the chisel-saw blade
1. Using the special EXCELION 2 wrench (23) supplied
with your tool, unscrew the nut clockwise while hol-
ding the protective bowl.
2. Remove in turn:
• the protective bowl,
• the chisel-saw blade (ref. 111700).
Removing the cutting head
1. Unscrew the two screws on the angle gear.
2. Remove the screw located on the right side of the
angle gear.
3. Take the tool transmission shaft (14) out of its hou-
sing.
4. Remove the cutting head.
35
