3
Chapter 2. Install PenMount 6000 Control Boards
The procedures that follow describe how to install and configure the hardware for each of the
PenMount 6000 Control Boards.
2.1. Installation Requirements
You need the following to install a touchscreen using a PenMount 6000 Touchscreen
Control Board:
2.1.1. Computer
1. An IBM-compatible host computer
2. A communications port, either RS-232 or USB (For 6300, only USB)
3. A Compact Disc drive
4. Operating systems required: See table “
O.S. that PenMount 6000
Boards Drivers Supports
” on page 2 for details.
2.1.2. Touchscreen
1. A 4-wire tail analog resistive touchscreen (for all 6000 boards)
2. A 5-wire tail analog resistive touchscreen (for all 6000 boards)
3. A 8-wire tail analog resistive touchscreen (for all 6000 boards except
6202B)
2.1.3. Control Board
1. A PenMount 6000 Touchscreen Control Board
2. Cables to connect the control board to the touchscreen and the
computer’s communications port.
3. The PenMount Drivers & Utilities disk.
4. A cable to connect the power supply. (This is only required when
connecting with RS-232 port).
