INTELLIVALVE
™
Valve Actuator Installation and User’s Guide
19
Problem: The IntelliValve actuator did not move or went back to the previous position
when the circuit was activated.
Action: Be sure that both end point positions are set. If not, reset both end points
(see Set Mode on page 9). If only one end point diverter position was set, the
actuator will revert to previous setting.
Problem: How do I reverse the end points? As in it’s stopping in the opposite
position, what did I do wrong?
Action: To change the Home position: When in AUTO mode, press the Red arrow
button and Yellow arrow button simultaneously. The diverter will rotate to the other
end point (the new home position). The factory default home position is 0. See page
11 for more information.
Problem: Unit is not able to move to assigned position (stuck). Power LED is blinking
Red and Green and the Service orange LED is on.
The IntelliValve Valve Actuator is not designed to be used in applications that involve
prolonged continuous operation, such as water features that demand continuous
diverter movement.
Action: Press the Mode button. The unit should return to normal operation.
Problem: The valve is not rotating when automation tells it to.
Action: Check that the IntelliValve actuator is in AUTO mode.
FAQ: What are these green and yellow communication wires for? These are
reserved for future use with future automation systems.
Troubleshooting
