Pentax ist DL User Manual

76570EM 25
16. 0-T940
(1) 0-T940
(2) TY-CNL-D1.7x3.0
(3) A115
(4) TY-CNL-G1.7x2.5
(5) Arrange four lead wires with
DT (4x15).
(6) T64 (PT 11x20)
3. Assembly procedure
1. Main body + Battery housing
(1) A13 Battery housing and relating parts.
[Caution]Check the position of lead wires and battery seal.
(2) Attach Main body to the A13.
(3) TY-CNL-D1.7x4.0 x 2
[Note of Disassembly]
When removing A115 and T940, Set AF-SW at AF position.
(5)
(1)
(2)
(3)
(4)
(6)
(3)
(2)
A16
A14(x4)
T
Y
-CNL-G1.7x3.5(x4)
T
Y
-CNS2.0x4.5
Black
Red
Gray
A
20
A
21
A
13
T
Y
-CNL-G1.4x3.5
Yellow
Black
(DT(5x5))
T10
T89(x3)
