USER MANUAL
Peplink Balance Series
Peplink Balance serves both the clients that are accessing from the specified IP addresses,
and the clients that are accessing from the LAN Interface (of the Peplink Balance unit).
Default SOA / NS
Click the button to define a default SOA / NS record for all Domain Names.For
Configuration details please refer to section15.3.5.
For defining a default SOA record, the field Name Server IP Address is optional. If left
blank, the Address (A) record for the same server should be defined manually in each
domain.
For defining default NS records, the host [domain] indicates that this record is for the
domain name itself without a sub-domain prefix. To add a secondary NS server, just create
a second NS record with the Host field empty. When the entered Name Server is a FQDN,
the IP Address field will be disabled.
Default
Connection
Priority
Default Connection Priority defines the default priority group of each WAN connection in
resolving A records. It applies to Address (A) records which have the Connection Priority
set to Default. Please refer to Section15.3.9 for the details.
The WAN connection(s) with the highest priority (smallest number) will be chosen. Those
with lower priorities will not be chosen in resolving A records unless the higher priority ones
become unavailable.
To specify the Primary and Backup connections, click the button that corresponds to
Default Connection Priority.The screen should assemble the one below.
Each WAN connection is associated with a priority number. Click Save to save the settings
when configuration is complete.
Domain name
This section shows a list of domain names to be hosted by the Peplink Balance. Each
domain can have its “NS”, “MX” and “TXT” records, andits sub-domains’ “A” and
“CNAME”records.Add a new record by clicking the New Domain Name button. Click on a
domain name to edit. Press to remove a domain name.
http://www.peplink.com -99 / 207 - Copyright © 2013 Peplink
