OXY5737A User’s Manual V1.1
www.perfectron.com
Chapter 2: Jumpers and Connectors
2.1 Jumpers and connectors list
Label
Function
BAT1
BATTERY connector
DIMMA1
DDR3 SO DIMM Socket
LVDS1
LVDS CONNECTOR
MCARD1
Mini PCIE Card Slot<COLAY M SATA>
MINI MPCIE
Mini PCIE Card Slot
SATA-CON CN3
Serial ATA Connectors
SATA-CON CN5
Serial ATA Connectors
PWR_S4P_H CN4
SATA POWER
PWR_S4P_H CN6
SATA POWER
LAN1
INTEL I218LM
LAN2
INTEL I210IT
F_USB1
USB2.0
CN18
USB3.0 X2
CN19
USB3.0 X2
MIC 1
Audio Jacks Connector
LOUT1
Audio Jacks Connector
DIO1
Digital I/O Box Head
SW2
POWER On/Off Switch
PWRIN1
DC Adapter Power Input
CN11
UPDATE BIOS
DP1
DISPLAY PORT
DP2
DISPLAY PORT
DVI
DVI-I
SIM_CARD_1
SIM card socket
JP7
COM3 +12/+5V selection
JP14
COM4 +12/+5V selection
JP15
COM5 +12/+5V selection
JP16
COM6 +12/+5V selection
COM1
RS232/422/485 with 5V/12V selectable
COM2
RS232/422/485 with 5V/12V selectable
COM3
RS232 with 5V/12V selectable
COM4
RS232 with 5V/12V selectable
COM5
RS232 with 5V/12V selectable
COM6
RS232 with 5V/12V selectable
DC JACK
DC connector
CON A1
CONNECTOE A TOP
CPU FAN
CPU FAN CONNECTOR
SYSFAN1
SYSTEM FAN CONNECTOR
JV8, JV9, JV10, JV11
LVDS Panel selection jumper setting
JV12
LVDS_VDD power select
LAN_SEL3
StackPC/I218 selection
LAN_SEL2
StackPC/I210 selection
MCARD_SEL1
mSATA and mPCIE selection
JV2, JV3
COM1 RS232/422/485 jumper setting
JV4
COM1 RS485 autoflow setting
JP12
COM1 5V/12V selection
JV7.JV6
COM2 RS232/422/485 jumper setting
JV5
COM2 RS485 autoflow setting
JP13
COM2 5V/12V selection
FPE1
StackPC FPE Top Connector
12
