OXY5737A User’s Manual V1.1
www.perfectron.com
1.2 Key Features
System
CPU Type
Intel® Haswell Core™ i7/i3, BGA type
Core i7-4700EQ (4C x 2.4/1.7GHz), 6M Cache, (47W/37W)
Core i3-4102E (2C x 1.6 GHz), 3M Cache (25W)
Celeron 2000E (2C x 2.2 GHz), 2M Cache (37W)
Chipset
Intel® Haswell QM87 PCH
Memory Type
1 x DDR3 1600 Swissbit XR-DIMM up to 8 GB with ECC
BIOS
AMI® UEFI BIOS
Supoer I/O
ITE8786
Watchdog
1-255 sec. or 1-255 min. software programmable
can generate system reset
Expansion Slot
2 x mPCIe (1 x SIM card, 1 x colay with mSATA)
Display
Chipset
Integrated GFX in Haswell processor
DVI-I
Yes (Max. resolution 2048 x 1536)
LVDS
Dual channel 24-bit LVDS
Display Type
2 x DP, LVDS, DVI-I (DVI-D+VGA)
Audio
Codec
Realtek ALC887 High Definition Audio Codec
Ethernet
Chipset
Intel® I210IT & i218-LM GbE
WOL
Yes
Boot from LAN
Yes for PXE
Rear I/O
DP
1
DVI-D
1
Ethernet
2 x RJ45
COM Port
1 x RS232/422/485 with 5V/12V selectable
USB
2 x USB 3.0
Audio
1 x MIC, 1 x Line out
Power Connector
1 (Terminal Block)
Internal I/O
Touch Panel
1 x 5-pin
Front Panel
1 (2 x 5-pin)
Smart Fan
1 x CPU Fan, 1 x System Fan
Power Connector
2 (1 x 4-pin/ 2 x 2-pin)
SATA
2 x SATAIII (6 Gb/s)
USB
2 x USB 2.0 by pin header
COM
5 x COM ports: 4 x RS232, 1 x RS232/422/485, all with 5V/12V
selectable
LVDS
2 x 15-pin
DIO
2 x 10-pin, 8 in/8 out with isolation
SIM card holder
1
