Azalia Docking Support: Enable or disable Azalia Docking Support of Audio Controller.
Azalia PME: Enable or disable Power Management capability of Audio Controller.
PCH LAN Controller
Enable or disable onboard NIC.
Wake on LAN: Enable or disable integrated LAN to wake the system. (The Wake On LAN cannot be
disabled if ME is on at Sx state.)
SLP_LAN# Low on DC Power: Enable/Disable SLP_LAN# Low on DC Power.
Board Capability
Board Capability-SUS_PWR_DN_ACK->Send Disabled to PCH, DeepSx->Show DeepSx Policies.
GP27 Wake From DeepSx
Wake from DeepSx by the assertion of GP27 pin.
PCIE Wake From DeepSx
Wake from DeepSx by the assertion of PCIE.
Serial IRQ Mode
Configure Serial IRQ Mode.
SLP_S4 Assertion Width
Select a minimum assertion width of the SLP_S4# signal.
Port 80h Redirection
Control where the Port 80h cycles are sent.
