Peri RCS P - Climbing Rail Hinge RCS; Climbing Rail Extension RCS 100; Climbing Rail Connector RCS 73

RCS-P
143
Item no. Weight kg
113744 21.000 Climbing Rail Connector RCS 73
For rigid connection of Climbing Rails RCS. Perm.
bending moment limited.
7
3
0
Ø26
8
0
180
2
5
0
1
2
5
2
5
0
45 45
Ø21
104031
018060
111567
022230
0.462
0.014
0.729
0.033
Accessories
Fitting Pin Ø 21 x 120
Cotter Pin 4/1, galv.
Fitting Pin Ø 26 x 120
Cotter Pin 5/1, galv.
109791 25.900 Climbing Rail Extension RCS 100
As extension of the Climbing Rail RCS for connec-
ting the finishing platform.
Complete with
2 pc. 109612 Bolt ISO 4014 M24 x 130-8.8, galv.
2 pc. 105032 Nut ISO 7040 M24-8, galv.
1
2
2
5
100
82
182
7
5
0
6
x
1
2
5
=
2
5
0
1
2
5
Ø26
M 24
110569 16.700 Climbing Rail Hinge RCS
For an articulated connection of the Climbing Rails
RCS and as pressure point on the RCS Climbing
Brackets.
Complete with
3 pc. 710894 Pin Ø 25 x 180, geomet.
4 pc. 018060 Cotter Pin 4/1, galv.
4
9
4
175
100
1
2
5
1
2
5
5
3
Ø26
Ø25
76
60
