Peri RCS P - Platform Girder

d dc
b
e
B
h
L
45
B2 Planning the Units
Fig. B2.04
Fig. B2.05
Platform Girder
The Platform Girders (timbers) are
dimensioned and proven on a pro-
ject-specific basis.
Solid Wood Strength Class C24 -
EN338 (Coniferous Wood S10).
Max. width of influence (eB) of the
Girder 0.50 m
Working platform load according
toScaffold Group 2:
Max. live load 150 kg/m²
Max. cantilever d ≤ 0.5 · c
RCS P Climbing Protection Panel
Instructions for Assembly and Use - Standard Configuration
