Peri RCS P - Overview of the Bracket Framework; Version 1; Version 2

1.1
1.2
94 + 95 11
2
2
94 + 95 94 + 95
11
94 + 95
11
94 + 95 94 + 95
94 + 95 94 + 95
12
94 + 95
94 + 95
10 10
12
12
280
348
748 / (998)
658
748
200
(748) 998
262,5
68,5
37,5
62,5
101,7
76
C1 Pre-Assembly of Brackets
Fig. C1.10
Fig. C1.11
Fig. C1.11a Fig. C1.11b
Fig. C1.10a
Version 2
Components
1.2 Climbing Rail RCS 748
2 Climbing Rail RCS
10 Crossbar RCS 103
12 Diagonal Strut RCS 212
94 Bolt ISO 4014 M24 x 130-8.8
95 Hex. Nut ISO 7042 M24-8
Overview of the Bracket
Framework
(Enclosure Post and Girder not shown
in order to provide a better overview)
Version 1
Components
1.1 Climbing Rail RCS 348 or 498
2 Climbing Rail RCS
11 Crossbar RCS 69
94 Bolt ISO 4014 M24 x 130-8.8
95 Hex. Nut ISO 7042 M24-8
RCS P Climbing Protection Panel
Instructions for Assembly and Use – Standard Configuration
