Peri RCS P - Version 3; Version 4

1.3 / 1.4 1.2
94 + 95
2
94 + 95
94 + 95
10
10
31
12
94 + 95
12
31 22.4
348 748 / 998
748 / (998)
77
C1 Pre-Assembly of Brackets
Fig. C1.13
Fig. C1.12
Fig. C1.12a
Version 3
Components
1.2 Climbing Rail RCS 748
1.3 Climbing Rail RCS 248
1.4 Climbing Rail RCS 148
2 Climbing Rail RCS
10 Crossbar RCS 103
12 Diagonal Strut RCS 212
31 Climbing Rail Connector RCS 73
94 Bolt ISO 4014 M24 x 130-8.8
95 Hex. Nut ISO 7042 M24-8
Version 4
Components
2.4 Climbing Rail RCS 348
2 Climbing Rail RCS
31 Climbing Rail Connector RCS 73
RCS P Climbing Protection Panel
Instructions for Assembly and Use – Standard Configuration
