RCS P Climbing Protection Panel
Instructions for Assembly and Use – Standard Configuration
Overview
Main Components
1 Enclosure Post
2 Climbing Rail RCS
10 Crossbar RCS 103 (concealed)
12 Diagonal Strut RCS 212
14 Enclosure Beam
18 Enclosure
36 Working Platform
41 Foldable Cover
44 Climbing Shoe RCS
45 Slab Shoe RCS
54 Slab Anchor Template 61 RCS
60 Climbing Device RCS 50
