Peri RCS P - Version 2

5 / 6
22
10
2
34
B1 Planning the Supporting Structure
Version 2
To mount the Enclosure Post with a
lower-positioned finishing platform
(14), install a Climbing Rail RCS 248 (5)
(L = 2.48 m) or Climbing Rail RCS 348
(6) (L = 3.48 m).
Attach Climbing Rails with Climbing
Rail Connectors RCS 33 (22) to Enclo-
sure Post 1.
(Fig. B1.09)
Fig. B1.09
RCS P Climbing Protection Panel
Instructions for Assembly and Use – Standard Configuration
