Peri RCS P - Climbing Protection Panel: Version 2 +3

46
45
14
14.1
40
39.1
39
14.1
14
c1
x
x
c1
1138 mm
50 mm
55
Components
14 Enclosure Beam (timber)
14.1 Bracing (multi-layer plywood
sheeting)
39 Toeboard
39.1 Angle Bracket 90°
40 Girder (timber)
45 Slab Shoe RCS
46 Slab Shoe RCS Corner
Fig. B3.04
Fig. B3.05
Climbing Protection Panel:
Version 2 +3
with wider working platforms, see
Section A1 System Overview.
Provide inclined support for the work-
ing platform in the mitred area. Guide
the Enclosure Beam (14) around the
corner up to the platform joint.
Reinforce the top and undersides of
the Enclosure Beam with multi-layer
plywood sheeting (14.1).
Assemble platform decking using mul-
ti-layer plywood sheeting in the mitred
area.
Cover the gap between the mitred en-
closure elements.
(Fig. B3.04 + B3.05)
B3 Corner Platforms
RCS P Climbing Protection Panel
Instructions for Assembly and Use – Standard Configuration
