Lambda 25, 35, 45 User’s Guide
64
Inscription legible
on Holder
Use in Spectrometer
LAMBDA
In this position, the cell holder can be used with all
Lambda Series Spectrometers.
BIO LAMBDA 2
The cell holder should be used in this position with
Lambda 25, 35, 45 Series Spectrometers. The smallest
beam diameter is exactly in the middle of the cell. This
is useful especially for operation with micro and semi-
micro cells.
Installing the Cell Holder
NOTE: Depending on the spectrometer, the single cell holder can be installed in two
different positions in the sample compartment. Always install the holder such that
the arrow on the cell holder lines up with the center point on the baseplate.
Install the single cell holder in the sample compartment as follows:
1. Orientate the holder so that the lifter is toward the rear of the sample
compartment.
2. Lower the holder so that the two alignment holes slip onto the two studs on the
baseplate at the bottom of the sample compartment.
The arrow on the cell holder must line up with the center point of the baseplate,
and
BIO LAMBDA 2 must be legible.
