Lambda 25, 35, 45 User’s Guide
94
1. Switch off the spectrometer and unplug the line power cord.
2. Remove the lamp compartment cover by pressing down the catch and pushing
the cover to the left.
3. Remove the lamp baffle by slackening the thumbscrew for the deuterium lamp
and lifting the lamp baffle vertically upward.
Figure 19 Lamp baffle
4. Carefully pull the white ceramic connector from the rear of the halogen lamp.
Thumbscrew
Thumbscrew
