Explorer Mini Repairs - Base module
Figure 44. Positions of the six screws on the top cover.
13. Push back the cable to the nVR2 power module through the hole
on the top cover.
14. Remove the six screws from the top cover.
Figure 45. Remove the top cover.
15. Remove the top cover from the base module.
28
