TIGHTENING TORQUES
12
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Body panels
Cycle part
Standard
Floor panel 4 Nm
Handlebar cover 1 Nm
Front shield panel 1 Nm
Rear shield 1 Nm
Side panels 1 Nm
Front mudguard 8 Nm
Front wheel spindle 65 Nm
Rear wheel spindle nut 110 Nm
Linkrod to engine pivot 50 Nm
Linkrod to frame pivot 50 Nm
Shock absorber top mount 45 Nm
Shock absorber bottom mount 22 Nm
Exhaust to cylinder head mounting nut 15 Nm
Exhaust to casing mounting bolt 20 Nm
Upper cone (in 2 operations) 40/23 Nm
Upper cone locknut Hand tightened
Steering locknut 70 Nm
Front brake caliper 30 Nm
Front brake disc 22 Nm
Handle bar 40 Nm
Fuel tank 22 Nm
Luggage carrier 25 Nm
Nut and bolt 5 mm diameter 6 Nm
Nut and bolt 6 mm diameter 10 Nm
Nut and bolt 8 mm diameter 22 Nm
Nut and bolt 10 mm diameter 35 Nm
