FUEL SYSTEM
43
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
FUEL SYSTEM
 Removal of the carburettor
- Remove the side fairings.
- Remove the fuel tank. See: Procedure 3
page 18.
- Disconnect:
• The throttle control (1).
• The fuel inlet pipe (2).
- Disconnect the carburettor heater (3).
- Remove the intake silencer (1 collar and
2screws).
- Disconnect the electric choke.
- Loosen the collar.
- Remove the carburettor.
Removal of the choke
- Remove the choke cap.
- Remove the screw and the holder plate.
- Locate the position of the choke (1) and then
remove it.
2
1
3
1
