FUEL SYSTEM
44
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Removal of the starter holder and its gasket
- Remove the choke holder and its gasket
(2 screws).
Check the condition of the O-ring.
Removal of the throttle valve
- Remove the chamber cap (2 screws).
- Remove the spring.
- Remove the needle, valve and membrane
assembly.
Check that the membrane is in good
condition.
- Remove the needle stop (1).
- Remove the spring (2).
- Remove the needle (3).
The height oif the needle is factory set
and cannot be modified.
1
2
3
