FUEL SYSTEM
49
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
The carburettor and its components
1. Choke.
2. Piston.
3. Sump.
4. Float.
5. Idle jet.
6. Main jet.
7. Needle well.
8. Needle valve.
9. Mixture screw.
10.Pick-up pump (10a and 10b).
11.Idle screw.
12.Pick-up pump suction valve.
13.Deceleration enrichment device.
14.Carburetor heater.
1
2
3
4
5
8
9
10b
11
12
13
14
6
7
10a
