SERVICE OPERATIONS
29
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Replacing the brake pads
- Remove the brake pad clips and pin (1).
- Remove the brake pad spring (2).
- Remove the brake pads (3).
When refitting the brake pads, push the
piston all the way into its housing.
Always use a new clip when refitting.
After refitting, actuate the brake levers
several times to bring the brake pads
against the brake disc.
Checking the brake fluid level
- Position the handlebars so that the master
cylinder will be horizontal.
- Check the brake fluid level and if necessary
top up in the master cylinder.
A. Maximum level.
B. Minimum level.
- Remove the cover and the
diaphragm from the master
cylinder (2 screws).
- Add brake fluid until it reaches the maximum
level.
1
2
3
A
B
