LOCATION OF COMPONENTS
15
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
LOCATION OF COMPONENTS
1. CDI unit
2. Battery
3. Magneto flywheel
4. Fuse
5. HT coil
6. Regulator
7. Starter motor relay
8. Switch "Reserve"
9. Horn
10.Starter resistor
11.Resistor warming carburator
12.Temperature control unit
-
U
P
P
E
R
L
E
V
E
L
L
O
W
E
R
L
E
V
E
L
5
11
1
2
9
8
6
7
3
4
12
10
