SERVICE OPERATIONS
23
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Removal of the spark plug
- Disconnect the suppressor (1).
- Remove the spark plug using tool
P/N 766062.
- Measure the distance between the
electrodes and correct it if necessary.
Electrode gap: 0.6 to 0.7 mm.
Essential precautions: When re-
installing, srew in the spark plug (a few
turns) by hand.
- Tighten the spark plug.
Tightening torque: 12 Nm.
Transmission
- Remove the transmission
cover (10 screw).
Tightening torque: 10 Nm.
Remove the paper gasket and the two 2
centering pins.
- Hold the fixed flange with tool P/N 752237.
- Remove the fixed flange nut and washer.
- Remove the fixed flange.
Tightening torque: 55 Nm.
1
