MISCELLANEOUS OPERATIONS
33
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
MISCELLANEOUS OPERATIONS
Removal of the fork
Replacing the bearings of the steering
system
- Remove the rear shield panel. See:
Procedure 2 page 16.
- Suspend or immobilize the machine
securely.
- Remove the front brake caliper from the fork
tube (2 screws).
Tightening torque: 30 Nm.
- Remove the front mudguard (3 screws).
- Remove the front wheel.
Tightening torque: 65 Nm.
When re-installing, use a new gasket.
- Remove the handlebars from the fork
tube (1 screw and 1 nut) (1).
Tightening torque: 40 Nm.
When re-installing, use a new gasket.
- Using tool P/N 757860 remove the steering
locknut.
- Remove:
• The brake washer.
• The nut.
• The rubber washer.
• the adjustable cone.
- Remove the fork.
- Remove the caged ball bearings.
1
