ELECTRICITY
 Ignition principle schematic/Carburetor heater
1. Ignition switch
2. Battery
3. CDI unit
4. Spark plug socket
5. Spark plug
6. HT coil
7. Resistor warming carburator
8. Temperature control unit
9. Choke
10.Magneto flywheel
11.Regulator
7,5A
OFF
ON
R
-
UP
P
E
R
L
E
V
EL
L
OW
E
R LE
V
EL
1 2
3
10
9
11
8 7
6
4
5
JN-BE
JN-BA
JN-NR
VE-NR
JN-BE
VE
RG
RG
NR
VE
VE
VE
VE
VEJN JN NR
