CHARACTERISTICS
5
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
CHARACTERISTICS
Engine
Capacities
Chassis
Engine marking XS1P37QMA-2
Type
4-stroke single-cylinder
2 valves per cylinder with chain driven overhead camshaft
Cooling
By a circulation of forced air by means of a turbine on the flywheel
magneto
Bore x stroke 37 x 46 mm
Cubic capacity 49 cc
Max. power output 3 kW at 8300 rpm
Max. torque rating 3.7 Nm at 6500 rpm
Compression
9.5 bars at 550 rpm
7bars Minimum
Fuel supply Carburettor. KEIHIN NCV
Lubrication
Pressurised wet sump lubrication.
Trochoid pump driven by a chain from the crankshaft
Transmission By 2 variable pulleys and V-type belt
Clutch Centrifugal automatic
Exhaust Catalytic
Starter motor By kick starter or electric starter
Spark plug
NGK CR6HSA
Electrode gap: 0.6 - 0.7 mm
Magneto flywheel 80 W
Standards Euro 2
Relay box
0.1 l SAE 80W90
Minimum grade: API GL4
(0.09 I at oil change)
Crankcase
0.8 l SAE 5W40
Minimum grade: API SL/SJ
(0.65 I at oil change)
Fuel tank 5.3 l
Chassis Tubular chassis
Front suspension
Upside down telescopic front fork
Travel: 73 mm
Rear suspension
Combined spring and hydraulically-damped shock absorber
Travel: 65 mm
