SERVICE OPERATIONS
30
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Rear brake linings
Check:
- Actuate the brake control lever and check
the position of the wear mark on the cam
tierod (A) compared to the mark (B) on the
engine housing.
- If the cam tierod mark is lined up with or
passes the wear mark on the engine
housing, the brake lining must be replaced.
Disassembly:
- Disconnect the air hose from the
exhaust (1).
- Remove the 2 screws from the exhaust.
Tightening torque: 20 Nm.
- Remove the 2 screws that secure the
muffler.
Tightening torque: 15 Nm.
- Remove the exhaust assembly.
Use a new exhaust gasket.
A
B
1
