MISCELLANEOUS OPERATIONS
36
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
- Install the rubber washer (6).
- Fit and finger tighten the nut (7) so that its
notches are aligned with those of the nut.
- Fit the lock washer (8) in the notches of the
locknut and adjustable cone.
- Use the tool ref. 757860 to tighten the
steering locknut (9).
Tightening torque: 70 Nm.
- Refit the other items in the reverse order to
disassembly.
Wheel bearing replacement
- Remove the wheel.
- Use an inertia extractor to remove the
bearings.
- Remove the spacer.
Reassembly
- Use a drift driver to fit the first bearing.
- Fit the spacer.
- Insert the wheel spindle to guide the spacer
with the bearings.
- Use a drift driver to fit the second bearing.
Use new bearings when refitting.
Fit the bearings, pressing against the
outer cage.
6
7
8
9
