FUEL SYSTEM
48
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
- Clean the carburettor body with Biosane
cleanser ref. 754748 or use an ultrasonic
cleaning tank.
- Blow into every jet and duct of the
carburettor body with compressed air.
Do not use any metal tool which can
damage the ducts of these items.
- Re-install all the other components and, if
necessary, when starting the engine,
readjust according to the values indicated
on the technical data card.
- When refitting the carburettor, adjust the
throttle tensioner to obtain a clearance on
the handlebar of:
A. 4 to 6 mm.
A
