FUEL SYSTEM
45
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Removal of the float, needle valve and jets
- Remove the float chamber and its O-ring
(4 screws).
Check the condition of the float
chamber O-ring.
- Loosen the float pin clamping screw (2).
- Remove the float (3), its pin (4) and the
needle valve (5).
- Remove the idle jet (6).
- Remove the main jet (7).
- Remove the needle well (8).
1
2
3
4
5
6
7
8
