FUEL SYSTEM
46
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
Check the condition of the needle valve
and the needle valve seat (A).
Removal of the mixture screw
- Turn clockwise the mixture control screw (1)
while counting the number of turns until it is
screwed home.
When re-fitting, this operation allows
you to put it back to its initial
adjustment position.
Removal of the pick-up pump
- Remove the 2 screws from the sheathing
holder plate.
- Remove the bushing (1) and the protective
rubber (2).
Check the condition of the bushing and
the rubber protection.
- Remove the piston (3).
A
1
2
1
3
