Adjustment
13 - 30
13.06.03 Knife position across the direction of sewing
Requirement
With the edge trimmer swung in, the knife 2 must be vertical and lightly touch the needle
plate insert.
Fig. 13 - 26
1
23
● Turn the machine off and swing in the edge trimmer.
● Position the knife 1 vertically by turning the milled screw.
● Bring the knife 2 lightly to rest against the needle plate insert and tighten screw 3.
The cutting pressure can be adjusted to suit the material used by turning milled
screw 1.
+
-
