Pfaff 1491E1 - Bobbin Case Opener Height

Adjustment
13 - 12
13.04.09 Bobbin case opener height
Requirement
The top edges of the bobbin case opener 1 and the bobbin case base 3 must be at the
same height.
● Move the bobbin case base 1 ( screws 2 ) in accordance with the requirement.
1
2
Fig. 13 - 08
3
1
